Leica DS2000 4-Wheel Radar Utility Detector without Controller
|
General |
|
|
Weight |
52.9 lbs (27 Kg) |
|
Protection |
IP65 ("dust tight" and protected against heavy seas or powerful jets of water) |
|
Power Consumption/Supply |
13.3 W / Rechargeable SLAB (Sealed Lead Acid Battery) 12 V DC, 12 Ah |
|
Operating Temperature Range |
–10° C to +40° C |
|
Frequency Antenna |
|
|
Antenna Footprint |
15.7 x 19.6 inches (40 x 50 cm) |
|
Hardware Channels |
2 |
|
Antenna Central Frequencies |
250 MHz and 700 MHz (Bandwidth 10-2000) |
|
Antenna Orientation |
Perpendicular, broadside |
|
Sampling Frequency |
400 kHz |
|
Data Acquisition |
|
|
Acquisition Speed |
More than 10 km/h |
|
Scan Rate per Channel |
381 scans per second |
|
Scan Interval |
42 scan per meter |
|
Positioning |
2 integrated encoders - GPS and/or TPS |
| Brochures | |
|---|---|
| LG847112 - Brochure | Datasheets |
| Leica DS2000 4-Wheel Radar Utility Detector without Controller - Datasheet | Installation Guides |
| Leica DS2000 4-Wheel Radar Utility Detector without Controller - Installation Guide | Product Manuals |
| Leica DS2000 4-Wheel Radar Utility Detector without Controller - Product Manual | Press Articles |
| Adelaide Advertiser - 24-09-18 - Utility Strike Incident - Case Study |
Brand: Leica Geosystems |
Code: LG847112
APN: 9319499014964 |
Supplier Code: 847112
Brand: Leica Geosystems |
Code: LG847112
APN: 9319499014964 |
Supplier Code: 847112
At a glance
Safely find out what’s going on underground before you dig with the new Leica DS2000 Utility Detection Radar.
